Duratec Engine to Toyota W Series Gearbox Bellhousing
Duratec Engine to Toyota W Series Gearbox Bellhousing
£264.60
Allows the Ford Duratec engine to be mated to the wide range of Toyota W series 5 speed gearboxes available. These gearboxes, in particular the DW56 are a strong and slick shifting alternative to the Sierra 5 speed boxes, which are increasingly in short supply.
If you are struggling to locate a Ford Type 9 gearbox then the Toyota W series gearboxes are a suitable replacement for rear wheel drive installations. Our bellhousing connects the Ford Duratec 4 cylinder engine to any of the range of gearboxes displayed below.
Specification and Application
| Component | Ford Duratec to Toyota W series |
| Type | Bare casting Machined on front and rear faces |
| Actuation | Hydraulic slave cylinder |
| Gearbox to Engine Face | 6.496 inch (165mm) |
| Engines | Ford 1.8 Duratec Ford 2.0 Duratec Ford 2.3 Duratec Ford 2.5 Duratec |
| Gearbox | Toyota W series including: W56 W58 |
| Applications | Kit cars Rally / race |
Additional information
| Weight | 5.5 kg |
|---|
